Weight: 2.15kg Impeller: Plastic PA6.6(glass-fibre reinforced) Number of blades: 11 Direction of rotation: Clockwise, seen on rotor Type of protection: IP44 Insulation: Class A Mode of operation: Continuous operation(S1) Safety: In process Operation Temperature: -20℃~+60℃
Listed Model |
Bearing System |
Rated Voltage |
Operation Voltage |
Frequency |
Rated Current |
Rated Speed |
Power |
Air Flow |
Air pressure |
Noise Level |
Available Features (Optional) |
Part NO. |
B / S |
VAC |
VAC |
Hz |
A |
RPM |
W |
CFM |
mmH2O |
dBA |
Tachometer Output |
Autorestart |
Pulse Width Modulation |
KE220HB2M |
B |
230 |
200~277 |
50/60 |
0.5 |
2,800 |
68 |
573 |
61.2 |
65 |
● |
● |
● | |
