Weight: 5.3kg
Impeller: Aluminum Sheet
Motor: DC brushless external rotor motor
Rotor: Black paint
Lead Wire: AWG#20 UL 1007
Insulation: Class B
Safety: In process
Operation Temperature:-25℃～+65℃
|
Listed
Model |
Bearing
System |
Rated
Voltage |
Operation
Voltage |
Rated
Current |
Rated
Speed |
Air
Flow |
Air
pressure |
Noise
Level |
Available Features (Optional) |
|
Part NO. |
B / S / F |
VDC |
VDC |
A |
RPM |
CFM |
mmH2O |
dBA |
Tachometer
Output |
Autorestart |
Pulse Width
Modulation |
|
KD48-400HB2M |
B |
48 |
36~56 |
4.2 |
1,290 |
1530 |
55 |
72 |
● |
● |
● | |
