Weight: 5.7kg
Impeller: Aluminum Sheet
Number of blades: 6
Direction of rotation: Clockwise, seen on rotor
Type of protection: IP44
Insulation: Class A
Mode of operation: Continuous operation(S1)
Safety: In process
Operating Temperature: -20℃～+60℃
|
Listed
Model |
Bearing
System |
Rated
Voltage |
Operation
Voltage |
Rated
Current |
Rated
Speed |
Air
Flow |
Air
pressure |
Noise
Level |
Available Features (Optional) |
|
Part NO. |
B / S / F |
VDC |
VDC |
A |
RPM |
CFM |
mmH2O |
dBA |
Tachometer
Output |
Autorestart |
Pulse Width
Modulation |
|
KD48-355HB2M-2 |
B |
48 |
36~56 |
4.9 |
1,560 |
1642 |
55 |
72 |
● |
● |
● | |
