Airflow: 405~495CFM Weight: 1.86kg Noise: 70~85dBA Impeller: Plastic PA6.6(polyamide glass-fibre reinforced) Injection-moulded round sheet-metal plate Motor: DC brushless external rotor Motor Rotor: Black paint Lead Wire: AWG#20 UL 1007 Insulation: Class B,Thermally protected Safety: In process Operation Temperature:-25℃~+65℃
Listed Model |
Bearing System |
Rated Voltage |
Operation Voltage |
Rated Current |
Rated Speed |
Air Flow |
Air pressure |
Noise Level |
Available Features (Optional) |
Part NO. |
B / S / F |
VDC |
VDC |
A |
RPM |
CFM |
mmH2O |
dBA |
Tachometer Output |
Autorestart |
Pulse Width Modulation |
KD28-200UB2M |
Ball |
28 |
18~32 |
8.6 |
4,300 |
450 |
114.3 |
80 |
● |
● |
● |
KD48-200UB2M |
48 |
36~56 |
5.2 |
4,300 |
450 |
114.3 |
80 |
● |
● |
● | |
